PIXEL
Dot type mini LED modules for application AS direct light signs.
3 years warranty
3 yearsIP 65
IP 65Color temperature: W, R, G, B, Y
W, R, G, B, YBeam angle: 120°
120°Constant current driver system
See PDF specification:
Choose the depth:
Suitable for this depth:
Dimensions:
Connection scheme:
Attention!
The maximum number of modules connected in one chain is 50 pcs.!
In case of use of the larger number of modules, please connect them to power supply by separate cables (parallel connection of chains)
| Type | PIXEL |
|---|---|
| Rated power/ forwarding current | Biały, zielony, niebieski, żółty- 0.1W/20mA Czerwony – 0.15W/30mA |
| Voltage | 5V |
| Luminous flux [Lm] | White – 6lm, Blue – 1.4lm, Green – 4,5lm, Yellow – 2lm, R-2,5lm |
| Light efficiency | White – 12lm/W, Blue – 2.7lm/W, Green – 8,5lm/W, Yellow – 3,8lm/W, R-4,6lm/W |
| Beam angle | 120° |
| Color | White, Red, Blue, Green, Yellow |
| Operating temperature | -30°C ~ 50 °C |
| Dimensions (diameter) | Ø9 |
| Module spacing [mm] | 72 mm |
| Chip | Epistar |
| IP rating | IP 65 |
| LED lifespan [h] | 50 000h |
| Maximum quantity in single chain | 50 pcs. |
| Warranty | 3 years |
